di-soric fork light barriers offer fast, precise detection of small objects. The OGU platform features a dual operating concept — IO-Link with four selectable sensor modes or direct manual potentiometer adjustment — all in the same compact housing. Fork widths range from 5 mm to 251 mm. The family includes the standard OGU series in red- and infrared-light variants, the OGU Stainless Steel series for hygiene-critical environments, the OGUP dirt-resistant series for maximum power reserve in oily or dusty areas, and the OGUL Laser series for detection of features as fine as 0.03 mm.
| Series | Housing | Fork Widths | Light Source | Best For |
|---|---|---|---|---|
| OGU Standard | Powder-coated metal | 5, 10, 20, 30–100, 120, 170, 220, 250 mm | Red LED or infrared LED | General-purpose; detection from 0.2 mm; up to 14,000 Hz |
| OGU Stainless Steel (V4A) | V4A stainless steel | 30, 50, 80, 120 mm | Red LED or infrared LED | Packaging, pharmaceutical, cosmetics — high hygiene requirements |
| OGUP Dirt-resistant | Powder-coated metal | 20, 30, 50, 80 mm | Infrared high-performance LED | Maximum power reserve in dusty, coolant, or oily environments |
| OGUL Laser | Powder-coated metal or V4A | 30, 50, 80, 120 mm | Laser | Detection down to 0.03 mm; reproducibility to 0.01 mm; medical & precision assembly |
| Mode | Switching Frequency | Reproducibility | Use Case |
|---|---|---|---|
| Standard | 5,000 Hz | 0.02 / 0.01 mm¹ | Balanced performance for most applications |
| High Resolution | 5,000 Hz | +30% improvement | Very small parts, precise position detection |
| Power | 5,000 Hz | 0.02 / 0.01 mm¹ | Dirty environments — increased transmit power, reduced dirt sensitivity |
| Speed | Up to 14,000 Hz | Standard | High-speed triggering on labelers, test benches, counting systems |
| Specification | Value |
|---|---|
| Protection class | IP67 |
| Connection | M8 connector (backward compatible) |
| Output type | Push-pull (pnp or npn in one device) |
| Operating temperature | –25 °C to 60 °C |
| IO-Link version | 1.1 with Smart Sensor Profile |
| Housing material | Powder-coated metal or V4A stainless steel |
¹ Fork light barriers OGU / OGUL with fork openings up to 80 mm. All specifications from di-soric OGU product documentation.
